Anticipating the global movement towards solutions that preserve the environment, improve the comfort of workers and minimize negative impact on the neighborhood, Geismar proposes a new global approach towards a sustainable railway world “the sustainable way to rail” which consolidates all its innovative electrically-powered solutions under the name Activion systems.
Thank you for registering to the Geismar Store.
Your request has been submitted to our Customer Service Department for approval. An e-mail notification will be sent shortly to confirm your account activation.
UNAUTHORISED ORDER
Only customer business addresses are allowed to order from the Geismar Store.To order by phone, please call +1 847-697-7510





| Engine | Diesel |
| Transport and rail mode dimensions | - Length with rail gear stowed: 3,969 mm (156.2 in.) - Length with rail gear deployed: 3,861 mm (152 in.) - Width: 1,725 mm (67.9 in.) |
| Track gauge | 1,435 mm (56.4 in.) (other gauges on request) |
| Maximum cant | 200 mm (7.8 in.) |
| Minimum curve radius | 80 m (262 ft.) |
| Rail transmission | Low ride |
| Maximum speed | - on road: 48 km/h (30 mph) - on rail: 32 km/h (20 mph) (dependant on local homologation) |
| Loading in deck | - 450 kg (992 lbs) - 2 x person mode - 150 kg (331 lbs) - 6 x person mode |
| Number of seats | - on road: 5 - on rail: 6 |
| Mass | 960 kg (2,120 lbs) |
Technical details are for information only
| Equipements | |
| Railway LED red/white directional lighting | |
| LED adjustable working lights | |
| Road & rail trailer towing points | |
| Full colour reversing camera | |
| Adjustable load deck length (mm): - 3 Person set up - Bed L: 1,085 W: 1,363 H: 279 - 6 Person set up - Bed L: 560 W: 1,363 H: 279 | |
| Mechanical/hydraulic Emergency Recovery System | |
| Steering wheel lock (for rail mode) | |
| Obstacle deflectors (rail sweeps) |
Technical details are for information only
